- 8 10/100/1000Mbps RJ45 ports
- Equipped with 8 PoE+ supported ports to transfer data and power over a single cable
- Works with IEEE 802.3af/at compliant devices, expanding home and office networks
- Innovative energy-efficient technology reduces power consumption
- Supports PoE+ standard with total power budget of 153W* and up to 30W per port
- Plug and play design, no configuration required
QoS for a Better Experience
Administrators can designate the priority of traffic to ensure specified applications, like voice and video, remain clear and lag-free.
Sturdy and Flexible Design
Compact metal casing, shielded RJ45 ports and desktop/wall mount design meet your needs in any environment.
Overload Protection
If all connected devices’ power consumption is greater than or equal to 126W, the switch will prioritize the ports and disable lower priorities.
Effective Management
Through its web-based management and utility, it also offers a variety of useful features, like network monitoring, traffic prioritization.
Secured and trusted checkout with

- Omschrijving
-
Details
Interface 8 10/100/1000Mbps RJ45 Ports
AUTO Negotiation/AUTO MDI/MDIXNetwork Media 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
EIA/TIA-568 100Ω STP (maximum 100m)
100BASE-TX: UTP category 5, 5e cable (maximum 100m)
EIA/TIA-568 100Ω STP (maximum 100m)
1000BASE-T: UTP category 5, 5e, 6 or above cable (maximum 100m)
EIA/TIA-568 100Ω STP (maximum 100m)Fan Quantity 1 Physical Security Lock No Power Supply 100-240VAC, 50/60Hz Packet Forwarding Rate 11.904 Mpps PoE+ Ports(RJ45) Standard: 802.3af/at compliant
PoE+ Ports: 8 Ports
Power Supply: 153WMac Address Table 4K Buffer Size 1.5Mbits Jumbo Frame 16 KB Switching Capacity 16Gbps Dimensions ( W x D x H ) 11.6*7.1*1.7 in. (294*180*44 mm) Mounting Desktop/Rack Mountable Max Power Consumption 8.57W(220V/50Hz. no PD connected)
173.65W(110V/60Hz. with 153W PD connected)Max Heat Dissipation 29.22BTU/h(no PD connected)
592.15BTU/h(with 153W PD connected)SOFTWARE FEATURES Advanced Features Compatible With IEEE 802.3af/at Compliant PDs
Priority Function
Mac Address Auto-Learning And Auto-Aging
IEEE802.3x Flow Control For Full-Duplex Mode And Backpressure For Half-Duplex ModeTransfer Method Store-And-Forward OTHERS Certification FCC, CE, RoHS Package Contents TL-SG1008MP, Power Cord, Installation Guide, Rackmount Kit, Rubber Feet Environment Operating Temperature: 0℃~50℃ (32℉~122℉)
Storage Temperature: -40℃~70℃ (-40℉~158℉)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing - Reviews
-
