UPS

ES Series IS-UL Interactive UPS Correct small power fluctuations (under voltage and over voltage) without using the battery. Extends battery life which is essential in areas where power fluctuations occur regularly. Typical applications are consumer electronics, PCs, network equipment, and mid-range servers.

Features:

• • Uninterrupted Power Supply
• • Corrects voltage drops and surges.
• • Battery outlets
• • Automatic voltage regulation
• • USB communication HID compliance.
• • Network RJ45 surge protection
• • Compact size, lightweight
• • Wide input voltage window
• • Compatible with generator and inverter

Office Series  UPS  offer high performance with Automatic Voltage Regulator preserves battery life for high efficiency and longer runtime.

Highlights:

• Uninterruptible Power Supply
• LCD or Led Display
• Corrects brownouts and over- voltages
• 12 protected outlets - 6 with battery backup
• Automatic Voltage Regulation
• 4 USB charging ports share 2 Amp.
• HID USB Compliance and network RJ45 and RG59 Coaxial protection
• Wide Input Voltage Window
• Battery access user replacement facility
• Build with ABS fire retardant material

Features

• On-line double conversion (VFI) technology from 1000VA to 3000VA with 0.9 power factor.
• Easy installation and maintenance due to easily user-replaceable battery.
• Low cost of ownership: high VFI efficiency and ECO functionality minimize energy consumption.
• High range expandability.
• Intuitive monitoring software, free downloadable and compatible with major operating systems, for: function control, diagnostics, controlled shutdown of loads in case of power failure.
• High capacity for overload management.
• Output mode with constant voltage and frequency (CVCF) to ensure maximum protection of particularly sensitive loads (e.g., electromedical equipment).
• Wide input voltage and frequency ranges that reduce battery tripping while increasing expected battery life and efficiency.
• Ability to set the battery power reserve percentage from 3 to 100% of available capacity.
• Display of accurate calculation of remaining range on the display.
• Two separately programmable IEC socket groups.
• Possibility of starting in the absence of the grid (cold start).
• Firmware easily upgraded to implement new functions.
• EPO and On/Off even remotely.
• RS232 and USB port, slot for additional communication card.
• CEI 0-16 compliant.
• Supplied with input and output power cables.

Main options:

• Boards: RS485, SNMP/web and dry contact relay board to send UPS status to various systems e.g., BMS, PLC, SCADA and AS400.
• External manual bypass with additional sockets.
• External battery cabinets.

Battery management:

• Set battery discharge limit level (3-100%) via included software.
• The UPS shuts down when the set battery power reserve level is reached.
• The UPS will be able to be turned back on manually even when there is no power.

Features

• On-line double conversion (VFI) technology from 1000VA to 3000VA with 0.9 power factor.
• Easy installation and maintenance due to easily user-replaceable battery.
• Low cost of ownership: high VFI efficiency and ECO functionality minimize energy consumption.
• High range expandability.
• Intuitive monitoring software, free downloadable and compatible with major operating systems, for: function control, diagnostics, controlled shutdown of loads in case of power failure.
• High capacity for overload management.
• Output mode with constant voltage and frequency (CVCF) to ensure maximum protection of particularly sensitive loads (e.g., electromedical equipment).
• Wide input voltage and frequency ranges that reduce battery tripping while increasing expected battery life and efficiency.
• Ability to set the battery power reserve percentage from 3 to 100% of available capacity.
• Display of accurate calculation of remaining range on the display.
• Two separately programmable IEC socket groups.
• Possibility of starting in the absence of the grid (cold start).
• Firmware easily upgraded to implement new functions.
• EPO and On/Off even remotely.
• RS232 and USB port, slot for additional communication card.
• CEI 0-16 compliant.
• Supplied with input and output power cables.

Main options:

• Boards: RS485, SNMP/web and dry contact relay board to send UPS status to various systems e.g., BMS, PLC, SCADA and AS400.
• External manual bypass with additional sockets.
• External battery cabinets.

Battery management:

• Set battery discharge limit level (3-100%) via included software.
• The UPS shuts down when the set battery power reserve level is reached.
• The UPS will be able to be turned back on manually even when there is no power.

Forza’s new SL series of smart UPS systems has been redesigned with a LCD touchscreen for ease of use through its user friendly interface which also displays power conditions in real time. The SL series counts with UL certification and is a complete solution for government agencies or private businesses in the educational, financing and public sectors. The integration of voltage regulation, surge suppression and backup capabilities in a single unit has made this one of the best-selling UPS systems in its class. The UPS comes with ForzaTracker monitoring software to easily administer the unit directly from your computer through a USB communication port. Long-lasting battery support along with complete power protection helps prevent data loss during mission critical operations

• MPN: SL-1501UL
• Capacity: 1500VA/900W
• Topology:
  Interactive
• Waveform:
  Simulated sine wave
• Voltage:
  120V
• Type of input:
  NEMA 5-15P
• Type of output:
  8 x NEMA 5-15R
• Communication:
  USB
• Visual indicator:
  Touchscreen LCD
• Management software:
  Forza Tracker

• MPN: SL-2001UL
• Capacity: 2000VA/1200W
• Topology:
  Interactive
• Waveform:
  Simulated sine wave
• Voltage:
  120V
• Type of input:
  NEMA 5-20P
• Type of output:
  8 x NEMA 5-15R
• Communication:
  USB
• Visual indicator:
  Touchscreen LCD
• Management software:
  Forza Tracker

 Interactive topology
Interactive UPS offer a cost effective solution with low energy consumption ratings, extending the overall life cycle of batteries. Voltage regulation is accomplished without switching to battery mode.

 Battery backup
Supplies battery-derived backup power during blackouts, preventing loss of critical information and minimizing equipment stress caused by a hard shutdown. Delivers reserved energy long enough for equipment to properly shut down.

 Automatic voltage regulation (AVR)
Provides clean and stable AC power by automatically increasing low voltages during brownouts and decreasing overvoltages without tapping into the reserved battery power when irregularities are present on the main utility line.

 Automatic shut-off
Guard your equipment against potentially damaging power fluctuations and other irregularities in the electrical supply by shutting down the power when voltage levels become too low or too high.

 Surge protection, overload protection, electric discharge and voltage protection
Diverts excess voltage away from connected equipment during power surges or power spikes without reducing battery power used to run primary critical equipment. Extends battery life by preventing system overloads and controlling charging currents.

 Resettable circuit breaker
Automatically prevents the flow of electricity in an electric circuit as a safety measure upon detecting undesirable high voltage levels. Can be reset to resume operation.

 MOV Technology
Metal Oxide Varistor (MOV) technology helps absorb and it redirects transient energy preventing stray electricity from reaching protected equipment.

 Thermofuse protection
Instantly disconnects the power when internal temperatures become dangerously high.

 Power filters
Reduces electromagnetic interference (EMI) and radio frequency interference (RFI) to block unwanted noise, providing clean and distortion-free electricity to all power outlets.

 Intelligent battery management
Maximizes battery performance, life, and reliability through intelligent, precision charging.

 Battery self-test
Ensures early failure notifications of bad or old batteries for immediate replacement, preventing any unexpected and unforeseen backup power issues.

 Audible alarm
Provides audible notification of changing utility power and UPS power conditions for when the UPS is installed in hard to reach places or not easily seen by the user.

 Flame retardant material
All of our products are constructed with fire retardant ABS material, guaranteeing that if any failures are present, the equipment will not go up in flames.

 Cold start function
Reserves temporary battery power used to start up the UPS in battery mode when the utility power is out. Restores immediate emergency power to the load after installing new batteries.

 Data line protection
Built-in data line protection prevents power surges that travel through telephone or Ethernet lines from causing damage to sensitive electronics.

 Silent design
Our fan-less design coupled with uniquely ventilated construction provides an overall solution ideal for quiet environments with less interference and noise obtained from moving internal components.

 Touch screen status LCD
State-of-the art touch screen cycles through live status of the UPS with detailed information on battery and power conditions, alerting users to potential problems before they can affect equipment and cause costly downtime.

 Communication ports
USB port enables the automatic shutdown function, safely powering down connected computers so as to prevent important data loss. Remotely manage and monitor UPS operations with the included user-friendly dashboard interface.

 Forza tracker management software
Allows control and monitoring of multiple UPS units through a network connection. The software also prevents data loss from power outages by safely shutting down the UPS units while allowing the immediate detection and correction of any operation issues with minimal or no delay.
