Highlights
- Uninterruptible power supply wiith line interactive topology
- Four (4) outlets with battery back-up and four (4) surge-only outlets
- Emergency backup power supply
Specifications
- Capacity: 700VA/375W
- Topology: Interactive
- Nominal voltage: 115V
- Voltage range: 75-144VAC
- Frequency: 50/60Hz (autosensing)
- AC plug style: NEMA 5-15P
- Nominal voltage: 115V
- Frequency: 50/60Hz
- Frequency stability: 50/60Hz ± 1Hz
- Waveform: Modified sine wave
- Total outlets: 8 (NEMA 5-15R)
- Battery backup: 4 surge protection outlets / AVR
- Surge protection only outlets : 4 surge protection only outlets
- Battery type and quantity: One 12V 5Ah cell
- Backup time: 10 minutes
- Recharge time: Recharges back to 90% of its capacity within 5 hours in line mode
- High cutoff : 140-148V
- Buck: 120-128V
- Boost 1: 98-106V
- Boost 2: 84-92V
- Low cutoff : 70-78V
- Typical transfer time: <6ms max="" li="">
- Visual indicators: Normal AC input: blue LED light
- Battery back-up: red LED light
- Audible alarm: Battery mode: beeps twice every 8 seconds.
- Low battery: beeps four times every second
- Overload and fault: beeps continuously
- Full protection: Line mode: 120% ± 10%, shuts down after 4 seconds and transfers to fault mode
- 0: Battery mode: 100% ± 10%, audible warning, will shut down after one minute, and then transfer to fault mode
- Power switch: Yes
- Cord length: 3.2ft
- Dimensions: 8x5.1x 3.8in
- Weight: 8.8lb
Secured and trusted checkout with
- Omschrijving
-
Details
Specifications- Capacity: 700VA/375W
- Topology: Interactive
- Nominal voltage: 115V
- Voltage range: 75-144VAC
- Frequency: 50/60Hz (autosensing)
- AC plug style: NEMA 5-15P
- Nominal voltage: 115V
- Frequency: 50/60Hz
- Frequency stability: 50/60Hz ± 1Hz
- Waveform: Modified sine wave
- Total outlets: 8 (NEMA 5-15R)
- Battery backup: 4 surge protection outlets / AVR
- Surge protection only outlets : 4 surge protection only outlets
- Battery type and quantity: One 12V 5Ah cell
- Backup time: 10 minutes
- Recharge time: Recharges back to 90% of its capacity within 5 hours in line mode
- High cutoff : 140-148V
- Buck: 120-128V
- Boost 1: 98-106V
- Boost 2: 84-92V
- Low cutoff : 70-78V
- Typical transfer time: <6ms max="" li="">
- Visual indicators: Normal AC input: blue LED light
- Battery back-up: red LED light
- Audible alarm: Battery mode: beeps twice every 8 seconds.
- Low battery: beeps four times every second
- Overload and fault: beeps continuously
- Full protection: Line mode: 120% ± 10%, shuts down after 4 seconds and transfers to fault mode
- 0: Battery mode: 100% ± 10%, audible warning, will shut down after one minute, and then transfer to fault mode
- Power switch: Yes
- Cord length: 3.2ft
- Dimensions: 8x5.1x 3.8in
- Weight: 8.8lb
